MPO/MTP Fan-out 0.9mm Patch Cord
Model: Data Center Cabling
The ORIENTELS' fan-out design is engineered for both low-loss and standard-loss SM and MM applications. Ruggedized round cable, oval cable, and bare ribbon options are available, and color-coded housings can be supplied to differentiate fiber type, polish type, and/or connector grade. The product offers good repeatability and exchangeability.
Product Features
- Economical solution for mass-termination of fiber
- Designed for low-loss and standard-loss SM and MM applications
- Ruggedized round cable
- oval cable
- and bare ribbon options available
- Color-coded housings available to differentiate fiber type
- polish type
- and/or connector grade
- Good repeatability and exchangeability
Applications
- Data communication network
- Optical system access network
- Storage area networking / fiber channel
- High-density architectures
Parameter Diagram
