400G QSFP56-DD Active Optical Cable
Model: 400G AOC
This AOC is an 8-Channel, Pluggable, Parallel, Fiber-Optic QSFP Double Density for Ethernet Applications. This AOC is a high performances module for short-range multi-lane data communication and interconnect applications. It integrates eight data lanes in each direction with 8x26.5625GBd. Each lane can operate at 53.125Gbps up to 70 m using OM3 fiber or 100 m using OM4 fiber with FEC.
| Form Factor | QSFP56-DD |
| Wavelength | 850nm |
| Cable Jacket | LSZH |
| Compatibility | Cisco, Huawei, Arista, Ciena, and more |
| Max Length | 70m |
| Power Comsumption | ≤10W |
| DDM/DOM | Supported |
| Warranty | 3 years |
Product Features
- Hot-pluggable QSFP-DD form factor
- Transmission data rate up to 53Gbps per channel
- 8x53Gbps PAM4 transmitter and PAM4 receiver
- 8 channels 850nm VCSEL array
- 8 channels PIN photo detector array
- RoHS6 compliant
Applications
- 400GBASE SR8 Ethernet
Testing & Quality
- RoHS/ UL/ CE/ TUV/ ISO14001/ ISO45001/ ISO9001
