200G HDR QSFP56 Active Optical Cable
Model: 200G AOC
This AOC is a Four-Channels, Pluggable, Parallel, Fiber-Optic QSFP56 for InfiniBand HDR Applications. This transceiver is a high performance module for short-range multi-lane data communication and interconnection applications. It integrates four data lanes in each direction.
| Form Factor | QSFP56 |
| Wavelength | 850nm |
| Cable Jacket | LSZH |
| Compatibility | Cisco, Huawei, Arista, Ciena, and more |
| Protocols | IEEE 802.3cd |
| Max Length | 70m |
| Power Comsumption | ≤5.5W |
| DDM/DOM | Supported |
| Warranty | 3 years |
Product Features
- Hot-pluggable QSFP56 form factor
- 4 channels full-duplex transceiver modules
- Transmission data rate up to 53Gbps per channel
- 4 channels 850nm VCSEL array
- 4 channels PIN photo detector array
- Low power consumption < 5.5W per end
- Post FEC Bit Error Rate (BER) better than 1E-15
- Built-in digital diagnostic functions
- Operating case temperature: 0℃~+70℃
- RoHS6 compliant
Applications
- InfiniBand HDR
Specifications
RoHS/ UL/ CE/ TUV/ ISO14001/ ISO45001/ ISO9001
