100G QSFP28 Active Optical Cable, Commercial-grade
Model: 100G AOC
This AOC is a Four-Channel, Pluggable, Parallel, Fiber-Optic QSFP28 AOC for 100 Gigabit Ethernet, Infiniband FDR/EDR Applications. This transceiver is a high performance module for short-range multi-lane data communication and interconnect applications. It integrates four data lanes in each direction with 100Gbps bandwidth.
| Form Factor | QSFP28 |
| Wavelength | 850nm |
| Cable Jacket | LSZH |
| CDR | YES |
| Compatibility | Cisco, Huawei, Arista, Ciena, and more |
| Protocols | IEEE 802.3bm |
| Max Length | 70m |
| Power Comsumption | ≤2.2W |
| DDM/DOM | Supported |
| Warranty | 3 years |
Product Features
- Four-channel full-duplex active optical cable with QSFP28 plugs
- Compliant to the IEEE 802.3bm(100GBASE-SR4)
- Compliant to the SFF-8665 Specification
- 4 channels 850nm VCSEL array
- 4 channels PIN photo detector array
- Low Power Dissipation <2.2W per end
- RoHS compliant
Applications
- IEEE 802.3bm 100GBASE SR4 Ethernet
Testing & Quality
- RoHS/ UL/ CE/ TUV/ ISO14001/ ISO45001/ ISO9001
