400G QSFP-DD LR4 10KM Fiber Optic Transceiver
Model: 400G
This product is a 400Gb/s Quad Small Form Factor Pluggable-double density (QSFP-DD) optical module designed for 10km optical communication applications. The module converts 8 channels of 50Gb/s (PAM4) electrical input data to 4 channels of CWDM optical signals, and multiplexes them into a single channel for 400Gb/s optical transmission. Reversely, on the receiver side, the module optically de-multiplexes a 400Gb/s optical input into 4 channels of CWDM optical signals, and converts them to 8 channels of 50Gb/s (PAM4) electrical output data.
| Form Factor | QSFP-DD |
| Wavelength | 1271/1291/1311/1331nm |
| Connector | LC |
| Distance | 10km |
| Inbuilt FEC | No |
| Working Temp | 0~70℃ / -40~+85℃ optional |
| Compatibility | Cisco, Huawei, Arista, Ciena, and more |
| Warranty | 3 years |
Product Features
- Hot-pluggable QSFP-DD form factor
- 4 CWDM lanes MUX/DEMUX design
- Duplex LC connector
- Compliant to QSFP-DD MSA
- 100G Lambda MSA 400G-LR4 Specification compliant
- Up to 10km transmission on single mode fiber (SMF) with FEC
- RoHS compliant
Applications
- 400G Ethernet
- Infiniband Interconnect
- Data center
- Enterprise Networking
Testing & Quality
- RoHS/ ISO14001/ ISO45001/ ISO9001
