Product Images

100G QSFP28 SR4 Fiber Optic Transceiver

ORIENTELS 100G QSFP28 SR4 module is a highly integrated 4x25G transceiver focused on reach, bandwidth, density and cost for high port-count 100G systems, and client-side 100G interfaces. Each lane can operate at 25Gbps up to 70m using OM3 fiber or 100m using OM4 fiber. These modules are designed to operate over multimode fiber systems using a nominal wavelength of 850nm. The electrical interface uses a 38-contact edge type connector. The optical interface uses a 12-fiber MPO connector.

Form Factor	QSFP28
Wavelength	850nm
Connector	MPO12
Distance	100m
Working Temp	0~70℃ / -40~+85℃ optional
Compatibility	Cisco, Huawei, Arista, Ciena, and more
Warranty	3 years
