10G SFP+ SR Fiber Optic Transceiver
Model: 10G
ORIENTELS 10G SFP+ SR Fiber Optic Transceiver is a Single-Channel, Pluggable, Fiber-Optic SFP+ for 10.3125Gbps SR Applications. It is a high performance module for short-range data communication and interconnect applications which operate at 10.3125Gbps up to 82m on OM2 MMF and 300m on OM3 MMF. This module is designed to operate over multimode fiber systems using a nominal wavelength of 850nm. The electrical interface uses a 20 contact edge type connector. The optical interface uses LC receptacle.
| Form Factor | SFP+ |
| Wavelength | 850nm |
| Connector | LC |
| Distance | 300m |
| Working temperature | 0~70℃ / -40~+85℃ optional |
| Compatibility | Cisco, Huawei, Arista, Ciena, and more |
| Warranty | 3 years |
Product Features
- Duplex SFP+ Transceiver
- Hot Pluggable
- LC connector receptacle
- Optical interface compliant to IEEE 802.3ae
- Electrical interface compliant to SFF-8431
- Data rate up to 11.3Gbps
- Maximum link length of 300m on OM3 MMF
Applications
- 10GBASE-SR at 10.3125Gbps
- 10GBASE-SW at 9.953Gbps
Testing & Quality
- RoHS/ UL/ CE/ TUV/ ISO14001/ ISO45001/ ISO9001
